Samsung DH55E - DH-E Series 55" Slim Direct-Lit LED Display
Reliable 24/7 Operation and Enhanced System-on-Chip Performance with a Quad Core CPU.

Samsung DH55E - DH-E Series 55" Slim Direct-Lit LED Display

Overview:

Samsung's DH55E displays feature quad core processing to display your most demanding images with ease on the 55" screen, while innovative cooling technologies afford reliable 24/7 operation. With 700 nits brightness, your message can be seen even in brightly-lit areas, and a slim, lightweight design allows for smooth installation plus a sophisticated look.

  • Reliable 24/7 Operation and Enhanced System-on-Chip Performance with a Quad Core CPU
  • High Def with 700-Nit Brightness, and a Sleek Industrial Design with a 9.5mm Bezel and Ultra-Slim 2.0" Chassis
  • Built-In Wi-Fi® for Expanded Connectivity
  • Transform Your Display with an Optional Touch Overlay for a PC-Less Touch Solution

Features

Reliable 24/7 Continuous Operation

These commercial displays are designed from the chassis up to deliver a high quality image with exceptional reliability, even during 24/7 continuous operation, thanks to innovative cooling technologies. So your business can meet around the clock operating requirements.

High Def with High 700-Nit Brightness

Experience sharp, stunning images with 1920 x 1080 Full HD resolution. And with 700-nit brightness, your message will be visible even in brightly-lit environments.

Enhanced SoC Performance with Quad-Core

Powered by a System-on-Chip (SoC) semiconductor and quad core CPU with 8GB of storage, Samsung's SMART Signage Platform is an open and integrated player side media platform that provides a powerful, streamlined solution to reduce TCO for digital signage deployments, through savings in hardware, installation and operating costs.

Sleek Industrial Design

The 9.5mm bezel provides a sleek, elegant look that can be polished with optional customizable color bezel trim kits. And the stylish, ultra-slim 2.0" chassis helps simplify installation while meeting ADA compliance requirements.

Built-In Wi-Fi®

Enjoy the versatility of expanded connectivity to mobile devices, from easy media sharing and screen control to simple content mirroring from a tablet or mobile phone to your display.

Optional Touch Overlay

The optional touch overlay accessory delivers a cost effective, PC-less touch solution that transforms your display into an interactive whiteboard with up to 10 simultaneous touchpoints. Create more collaborative presentations or a dynamic customer experience with tangible results for your business.

MagicInfo S3 Digital Signage Software

Create playlists, set playback schedules and publish content directly to the display with this software. Most traditional file formats are supported including RSS feed and live web pages.

Specifications:


Samsung DH55E - DH-E Series 55" Slim Direct-Lit LED Display Specifications
Display
Screen Size 55"
Panel Technology 60Hz Slim D-LED BLU
Resolution 1920x1080 (16:9)
Brightness 700 nits
Contrast Ratio 5000:1
Viewing Angle (Horizontal/Vertical) 178° / 178°
Orientation Landscape / Portrait
Response Time (G-to-G) 8ms
Connectivity
Input VGA (D-Sub 15 Pin), DVI-D (HDMI Common), DisplayPort 1.2, HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included), Component/Composite, Stereo Mini Jack, USB 2.0 x 1
Output DisplayPort 1.2 (Loop-Out), Stereo Mini Jack
External Control RS232C (In/Out) thru Stereo Jack, RJ45
External Sensor IR, Ambient Light
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical/Max) 70W / 175W
Power Consumption (Standby) & 0.5W
Environmental Conditions
Operating Temperature 0°C - 40°C
Operating Humidity 10%~80%
Features
  Slim and Light LFD with Built-in MagicInfo Player S3
Special Hardware: Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery(80hrs Clock Keeping), Built in Speaker (10Wx1), Wi-Fi Module Embedded, SD Card Slot

Software: Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC, Plug and Play (DDC2B), PIP/PBP, Image Rotation, Built-in MagicInfo S3, Firmware Update by Network, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch
Tuner Yes
SMART Signage Platform Compliant Yes
Internal Media Player Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage, USB 2.0, Samsung Proprietary OS (VDLinux)
VESA Standard Wall Mount Interface 400 x 400mm
24/7 Operation Yes
Dimensions
Product Dimensions (without stand) 48.7" x 28.1" x 2.1"
Packaging Dimensions 55.8" x 31.9" x 5.1"
Bezel Width 9.5mm (Top, Side), 15.0mm (Bottom)
Weight
Product Weight 34 lbs.
Shipping Weight 43 lbs.
Service
Standard Warranty 3 Years On-Site (Parts / Labor / Backlight)
Accessories
Included Quick Setup Guide, Warranty Card, D-Sub Cable, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)
Optional Mount WMN4270SD, WMN250MD
Optional Stand STN-L4055AD, STN-L4655E
Media Player SBB-DA, SBB-DI, SBB-B32D, PIM-PB32E, PIM-BF7P, PIM-PB28E, PIM-PB56E
Optional Touch Overlay CY-TD55LDAH
Optional Bezel Trim Kit CY-BD55BD (Matte Black), CY-BD55WD (White)
Optional HDBase-T Receiver PIM-HDBT
Green Management
Emission Standard EMC
ENERGY STAR® 6.0 Compliant Yes
RoHS Compliant Yes
Packaging Recyclability Packing Materials Recyclable

Compare:


Samsung DH55E - DH-E Series 55" Slim Direct-Lit LED Display
Model Number DH40E DH48E DH55E
Display
Screen Size 40" 48" 55"
Panel Technology 60Hz Slim D-LED BLU 60Hz Slim D-LED BLU 60Hz Slim D-LED BLU
Resolution 1920x1080 (16:9) 1920x1080 (16:9) 1920x1080 (16:9)
Brightness 700 nits 700 nits 700 nits
Contrast Ratio 5000:1 5000:1 5000:1
Viewing Angle (Horizontal/Vertical) 178° / 178° 178° / 178° 178° / 178°
Orientation Landscape / Portrait Landscape / Portrait Landscape / Portrait
Response Time (G-to-G) 8ms 8ms 8ms
Connectivity
Input VGA (D-Sub 15 Pin), DVI-D (HDMI Common), DisplayPort 1.2, HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included), Component/Composite, Stereo Mini Jack, USB 2.0 x 1 VGA (D-Sub 15 Pin), DVI-D (HDMI Common), DisplayPort 1.2, HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included), Component/Composite, Stereo Mini Jack, USB 2.0 x 1 VGA (D-Sub 15 Pin), DVI-D (HDMI Common), DisplayPort 1.2, HDMI1, HDMI2 (thru DVI-D Input, Adapter Not Included), Component/Composite, Stereo Mini Jack, USB 2.0 x 1
Output DisplayPort 1.2 (Loop-Out), Stereo Mini Jack DisplayPort 1.2 (Loop-Out), Stereo Mini Jack DisplayPort 1.2 (Loop-Out), Stereo Mini Jack
External Control RS232C (In/Out) thru Stereo Jack, RJ45 RS232C (In/Out) thru Stereo Jack, RJ45 RS232C (In/Out) thru Stereo Jack, RJ45
External Sensor IR, Ambient Light IR, Ambient Light IR, Ambient Light
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical/Max) 48W / 135W 54W / 145W 70W / 175W
Power Consumption (Standby) < 0.5W < 0.5W < 0.5W
Environmental Conditions
Operating Temperature 0°C - 40°C 0°C - 40°C 0°C - 40°C
Operating Humidity 10%~80% 10%~80% 10%~80%
Features
Special Hardware Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery(80hrs Clock Keeping), Built in Speaker (10Wx1), Wi-Fi Module Embedded, SD Card Slot Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery(80hrs Clock Keeping), Built in Speaker (10Wx1), Wi-Fi Module Embedded, SD Card Slot Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery(80hrs Clock Keeping), Built in Speaker (10Wx1), Wi-Fi Module Embedded, SD Card Slot
Software Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC, Plug and Play (DDC2B), PIP/PBP, Image Rotation, Built-in MagicInfo S3, Firmware Update by Network, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC, Plug and Play (DDC2B), PIP/PBP, Image Rotation, Built-in MagicInfo S3, Firmware Update by Network, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch Magic Clone (to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC, Plug and Play (DDC2B), PIP/PBP, Image Rotation, Built-in MagicInfo S3, Firmware Update by Network, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch
Tuner Yes Yes Yes
SMART Signage Platform Compliant Yes Yes Yes
Internal Media Player Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage, USB 2.0, Samsung Proprietary OS (VDLinux) Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage, USB 2.0, Samsung Proprietary OS (VDLinux) Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB Storage, USB 2.0, Samsung Proprietary OS (VDLinux)
VESA Standard Wall Mount Interface 200 x 200mm 400 x 400mm 400 x 400mm
24/7 Operation Yes Yes Yes
Dimensions
Product Dimensions (without stand) 36.0" x 20.9" x 2.1" 42.6" x 24.6" x 2.1" 48.7" x 28.1" x 2.1"
Packaging Dimensions 41.8" x 23.6" x 4.5" 49.5" x 28.3" x 5.1" 55.8" x 31.9" x 5.1"
Bezel Width 9.5mm (Top, Side), 15.0mm (Bottom) 9.5mm (Top, Side), 15.0mm (Bottom) 9.5mm (Top, Side), 15.0mm (Bottom)
Weight
Product Weight 16.6 lbs. 24.5 lbs. 34 lbs.
Shipping Weight 20.1 lbs. 30.9 lbs. 43 lbs.
Service
Standard Warranty 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight) 3 Years On-Site (Parts / Labor / Backlight)
Accessories
Included Quick Setup Guide, Warranty Card, D-Sub Cable, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA) Quick Setup Guide, Warranty Card, D-Sub Cable, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA) Quick Setup Guide, Warranty Card, D-Sub Cable, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Cover-Jack, Screw (M3L8, 1EA) (M4L8, 4EA)
Optional Mount WMN4070SD, WMN250MD WMN4270SD, WMN250MD WMN4270SD, WMN250MD
Optional Stand STN-L4055AD, STN-L3240E STN-L4055AD, STN-L4655E STN-L4055AD, STN-L4655E
Media Player SBB-DA, SBB-DI, SBB-B32D, PIM-PB32E, PIM-BF7P, PIM-PB28E, PIM-PB56E SBB-DA, SBB-DI, SBB-B32D, PIM-PB32E, PIM-BF7P, PIM-PB28E, PIM-PB56E SBB-DA, SBB-DI, SBB-B32D, PIM-PB32E, PIM-BF7P, PIM-PB28E, PIM-PB56E
Optional Touch Overlay CY-TD40LDAH CY-TD48LDAH CY-TD55LDAH
Optional Bezel Trim Kit CY-BD40BD (Matte Black), CY-BD40WD (White) CY-BD48BD (Matte Black), CY-BD48WD (White) CY-BD55BD (Matte Black), CY-BD55WD (White)
Optional HDBase-T Receiver PIM-HDBT PIM-HDBT PIM-HDBT
Green Management
Emission Standard EMC EMC EMC
ENERGY STAR® 6.0 Compliant Yes Yes Yes
RoHS Compliant Yes Yes Yes
Packaging Recyclability Packing Materials Recyclable Packing Materials Recyclable Packing Materials Recyclable

Documentation:

Download the Samsung DH-E 40"/48"/55" Commercial LED LCD Displays Datasheet (.PDF)

It appears you don't have a PDF plugin for this browser. No biggie... you can click here to download the PDF file.
