Our 690U Series Hospitality TVs feature 4K UHD (Ultra High Definition) resolution to provide an outstanding in-room viewing experience. With these SMART TVs, guests can watch movies and TV shows from streaming services, check Facebook, Twitter and Skype to stay connected, and even push content from their mobile devices to the big screen in dazzling quality.
Premium Slim Direct-Lit LED
Direct-lit LED technology provides the brilliance and energy savings advantages of LED technology, along with the uniform brightness typical of CCFL displays. And it's possible to upgrade your rooms to LED technology for a cost comparable to CCFL technology.
Samsung LYNK REACH® 3.1 Content Management Solution
The Samsung LYNK REACH® 3.1 (Remote Enhanced Active Control for Hotels) content management solution is used in conjunction with an existing coaxial-based infrastructure. It provides centralized TV controls, basic static content management capabilities and an Interactive Program Guide (IPG).
Samsung LYNK® SINC 3.1 Interactive Content Management System
H-Browser Compatibility
Built on the HTML5 standard with Flash® support, H-Browser is a true SMART TV solution offered on our 690U Series through partnerships with certified system integrators. It features both free and video on demand (VOD) content, and is able to interface directly with the head end without a set top box.
Mobile Device Integration Using AllShare® Cast
Seamlessly share content across your DLNA connected Samsung devices including WIDI without the need for a network cable or a connecting device. AllShare® Cast allows screen mirroring and video streaming to enable seamless content sharing and mobile device integration.
A Host of Features and Swivel Stand
Features include: LYNK DRM, Pro:Idiom® DRM, BT Music, Home Menu, RJ12 IR PASS, Volume Limiters, Front Panel Lock-out, Menu Display Lock-out, Hotel Custom Logo/Welcome Message, and Channel List Guide, Channel Re-mapping, Remote Jack Pack (RJP) Priority, USB Cloning and Anti-Theft Battery Cover Remote Control. A swivel stand rotates 90° in both directions with optional 20, 60 and 90 degree stops.
Samsung 48" 690U Series Premium 4K UHD Slim Direct-Lit LED Hospitality TV Specifications | |
---|---|
Display | |
HD/FHD | UHD |
Design | |
Type | Slim Direct-Lit LED |
Video | |
Screen Size (Diagonal) | 48" |
Film Mode | Yes |
Native Resolution | 3,840 x 2,160 |
Picture Engine | UHD Up-Scaling |
Tuners | ASTC/Clear QAM |
Auto Motion Rate | Auto Motion Plus |
Features | |
Apps Platform | Yes |
Auto Channel Search | Yes |
Hotel Channel List | Yes |
USB Cloning | Yes |
Hospitality Plug & Play (Easy Set-up) | Yes |
OSD Language | English, Spanish, French |
Closed Captioning | Yes |
Music Mode (Input: PC/AV/Component) | Yes |
Auto Power Off | Yes |
ConnectShare (USB 2.0) | Yes |
Music Mode Backlight On/Off | Yes |
Game Mode | Yes |
Hospitality Features | |
Samsung Lynk Reach | Yes |
Logo Display With Time Out Setting (BMP/Movie) | Yes |
Clock Back Up Supply | Yes |
Smoovie Compatibility | Yes |
Samsung Lynk Reach Server Compatibility | Yes |
Welcome Message | Yes |
Software Clock | Yes |
Sound Bar Compatibility | Yes |
Samsung Lynk Sinc Compatibility | Yes |
Auto Source Mode | Yes |
Multi Code Remote Control | Yes (TM1240) |
Power On Mode | Yes |
Energy Saving Mode (Blu Control) | Yes |
Screwed Remote Battery Cover | Yes |
Connectivity | |
HDMI | 3 |
USB (Side/Rear) | 2/0 |
Digital Audio Out (Optical) (Side/Rear) | 0/1 |
Component (Side/Rear) | 0/1 |
Hotel TV (RJ-12 IR Pass Through) | Yes |
Composite In (AV) (Side/Rear) | 1 (Common Use for Component Y) |
PC Audio Jack | 1 |
Ethernet (RJ45/LAN) | 1 |
Audio Out (Mini Jack) (Side/Rear) | 0/1 |
Audio | |
Speaker Type | 2CH(Down Firing + Base Reflex) |
Sound Output (RMS) | 20W(L:10W, R:10W) |
Dolby | Dolby Digital Plus (MS11) |
DTS Studio Sound/DNSE+ | DTS Studio Sound |
DTS Premium Sound/DTS Premium Sound 5.1 | DTS Premium sound 5.1 |
Dimensions | |
Product Size (W x H x D) Without Stand | 42.80" x 24.84" x 1.98" |
Product Size (W x H x D) With Stand | 42.80" x 26.65" x 10.02" |
DRM Type | |
Samsung Lynk DRM | Yes |
Pro:Idiom DRM | Yes |
Power | |
Power Supply | AC110-120V 60Hz |
